Fix timeout errors in proxy service caused by circuit breaker configuration

  • Updated

Issue

Users may encounter a 504 Gateway Timeout error when sending requests to a query pipeline endpoint in Fusion. The response includes a message similar to the following:

"error": "service-timeout",
"msg": "Did not observe any item or terminal signal within 15000ms in 'circuitBreaker' (and no fallback has been configured)",
"path": "/api/apps/<app-name>/query/<pipeline-name>"
This error typically originates from the proxy (api-gateway) microservice and indicates that a response was not received within the configured timeout period managed by Resilience4j.


Cause

Fusion's proxy service uses Resilience4j for circuit breaker functionality. If the timeoutDuration value for the query instance is too low relative to downstream processing latency, the circuit breaker will trigger a timeout before receiving a response. This results in the service-timeout error and a 504 response code.


By default, the value may be set to 15 seconds (15000ms) on the api-gateways. In some environments, this timeout may be too aggressive for longer-running query requests.


Resolution

To increase the timeout and prevent premature circuit breaker termination in the proxy service:
  • Identify the api-gateway deployment in your Fusion Kubernetes namespace. This is typically named using the pattern: <namespace>-api-gateway
  • Edit the deployment configuration using kubectl:

    kubectl edit deploy <namespace>-api-gateway -n <namespace>
  • Locate the args: section under containers: and add or modify the following line:

    --resilience4j.timelimiter.instances.query.timeoutDuration=15s



    This sets the timeout duration for the query circuit breaker instance to 15 seconds. Adjust the value based on your system’s expected response times.

    Screenshot 2023-08-17 at 11.37.42 AM (1) (1).png


  • Save and exit the editor to apply the changes.
  • Monitor the pod rollout to ensure that the updated configuration is applied.
  • You can confirm the new pods are running.
Additional guidance
  • Apply configuration changes in a lower environment first to validate expected behavior before deploying to production.
  • Avoid setting excessively high timeout durations, as this can delay failure detection and degrade system responsiveness under load.
For persistent or unclear timeouts, contact the Lucidworks Support Team for further assistance.
